Hot dip galvanized square hollow square steel pipe

Galvanized square pipe is a kind of name of square pipe and rectangular pipe, that is, steel pipe with equal side length. It is made of strip steel through processing and rolling. Generally, strip steel is unpacked, leveled, crimped, welded to form a round tube, which is then rolled into a square tube and cut to the required length.

Inquiry WhatsApp Email
Tel +86-531-88752665

〣Description


Galvanized square pipe is a kind of name of square pipe and rectangular pipe, that is, steel pipe with equal side length. It is made of strip steel through processing and rolling. Generally, strip steel is unpacked, leveled, crimped, welded to form a round tube, which is then rolled into a square tube and cut to the required length. Usually 50 sticks per pack. Also known as square and rectangular cold-formed hollow steel, square pipe and rectangular pipe for short, code F and J respectively

1. The allowable deviation of the wall thickness of galvanized square rectangular pipe shall not exceed plus or minus 10% of the nominal wall thickness when the wall thickness is less than 10mm, and plus or minus 8% of the wall thickness when the wall thickness is more than 10mm, except the wall thickness of the corner and weld area.

2. The usual delivery length of galvanized square tube is 4000mm-12000mm, with 6000mm and 12000mm as the majority. Square rectangular pipe is allowed to deliver not less than 2000mm short and non-fixed size products, can also be delivered in the form of interface pipe, but the customer should be in use when the interface pipe should be removed. The weight of short size and non-fixed size products shall not exceed 5% of the total delivery, for the theoretical weight of more than 20kg/m square pipe shall not exceed 10% of the total delivery.

3. The bending degree of galvanized square rectangular pipe shall not be greater than 2mm per meter, and the total bending degree shall not be greater than 0.2% of the total length.


〣Use


Mainly used in curtain wall, construction, machinery manufacturing, steel construction projects, shipbuilding, solar power generation bracket, steel structure engineering, power engineering, power plant, agriculture and chemical machinery, glass curtain wall, automobile chassis, airport and so on.


〣parameter


  Name

 Square and rectangular steel pipe

  Outside Diameter

  20*20-200*200 mm

  Wall Thickness

  1.5-30 mm

  Length

  1-12 m

  Packing

  Export standard packing or according to customers’ requirement

  Certificate

  ISO9001:2008,SGS

  Shipment

  Within 10-15 workdays,25-30 days when the quantity beyond 1000 tons


〣Advantages


1.Reasonable price with excellent quality2.Abundant stock and prompt delivery3.Rich supply and export experience, sincere service4.Reliable forwarder, 2-hour away from port.


〣Packaging


Loose package; Packaged in bundles(2Ton Max); bundled pipes with two slings at the both end for easy loading and discharging;wooden cases; waterproof woven bag.


〣FAQ


Q1: Are you a manufacturer?

A: Yes, we are a manufacturer, we have our own factory.  And we are the China leading galvanized steel coil, galvalume steel coil,PPGI/PPGL etc.  We promise that we are exactly the supplier you have been looking for.  We welcome you to visit our factory to check our production lines and know more about our capacity, quality.

Q2: Do you have quality control system?

A: Yes, we have ISO, BV, SGS certifications and our own quality control laboratory.

Q3: How long is your delivery time?

A: Generally it is 7-14 days if we have the exact goods in our stock.  If not, it will take around 25-35 days to get goods ready for delivery.
