1.2mm Thick Galvanized Steel Sheet Hot Dipped Steel Plate Iron Steel Galvanized Metal Sheet

1.2mm Thick Galvanized Steel Sheet Hot Dipped Steel Plate Iron Steel Galvanized Metal Sheet. The base material is mostly Q235B cold-rolled steel plate (yield strength ≥235MPa, tensile strength 370-500 mpa).

Inquiry WhatsApp Email
Tel +86-531-88752665

1.2mm Thick Galvanized Steel Sheet Description


The key information about 1.2mm thick hot-dip galvanized steel plates is summarized as follows:


I. Core Specifications and Performance

1. Substrate and coating

    The base material is mostly Q235B cold-rolled steel plate (yield strength ≥235MPa, tensile strength 370-500 mpa).

    The total weight of the hot-dip galvanized coating on both sides is 275g/m² (Z275 standard), forming a zinc-iron alloy layer with a thickness of approximately 19.26μm. There is no red rust for 1000 hours in the salt spray test, and it remains intact after the wet heat cycle test.

2. Processing characteristics

    It supports processes such as bending, stamping and welding. The closed die design (such as the YXB75-230-690 model) can enhance the seismic performance, with the seismic displacement Angle controlled within 1/200.

Ii. Typical Application Scenarios

1. Field of architecture

    Roof and walls: A certain logistics center in Shanghai uses 1.2mm thick galvanized profiled steel sheets for the roof, with a wind resistance capacity of 5.0kPa (typhoon level 12), reducing maintenance costs by 30%.

    Floor deck: Such as YXB60-253-760(B) type closed profiled steel sheet, with an effective coverage width of 760mm, a section moment of inertia of 48.6cm⁴/m, and a flexural strength of 18.5kN·m, it is a permanent formwork suitable for pouring concrete.

2. Transportation and Infrastructure

    Highway guardrails, railway sound barriers, power transmission towers, etc., taking advantage of their salt spray corrosion resistance, can have a service life of over 30 years in coastal or industrial areas.

3. Industrial equipment

    The shell of evaporative cooling equipment, mine transmission pipelines, etc., the self-healing property of the zinc coating can resist the corrosion of acid and alkali media, thus extending the service life of the equipment.



Galvanized Steel Sheet Parameter


Product name

Galvanized steel sheet/coils

Standard

JIS G3302 / ASTM A653M / EN10327 / DIN17162

Grade

SGCC/DC51D/DX51D/DX52D/SGSS/SGCD1/SGCD2/SGCD3 SGCC,etc

Thickness

0.12-3.5 mm

Width

600-1250mm(usual size:914mm,1000mm,1200mm,1219mm,1250mm,1220mm)

Spangle

Regular spangle,Minimum spangle, Zero spangle, Big spangle

Zinc coating

30~600G/M2

Hardness

Soft hard(HRB60),medium hard(HRB60-85),full hard(HRB85-95)

Coil ID

508mm, 610mm

Packing

Standard seaworthy export packing: waterproof paper+steel trippacked+wooden case seaworthy package

Delivery

Within 7-15days

Standard Seaworthy Export Packing

Dust-proof kraft sheet, Iron packing, Angle protective ,Packing belt,Wood pall




FAQ


Q:Can you send samples?

A:Of course, we can send samples to all parts of the world, our samples are free, butcustomers need to bear the courier costs.

Q:What are the shipping ports?

A:Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, youcan choose other ports according to your needs.

Q:What are the certifications for your products?

A:We have ISO 9001,SGS,EWC and other certifications.

Q:How long does your delivery time take?

A:ln general, our delivery time is within 30-45 days, and may be delayed if the demand is extremely large or special circumstances acc1 5%

Q:Can I go to your factory to visit?

A:Of course, we welcome customers from all over the world to visit our factory.  However.  some of the plants are not open to the public.

Q:Does the product have quality inspection before loading?

A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.

Q:How to pack the products?

A:The inner layer has a waterproof paper outer layer with iron packaging and is fixed witha fumigation wooden pallet.  lt can effectively protect products from corrosion during oceantransportation.
